天線型號

工作頻段

極化方式

增益

3dB寬度

駐波比

前后比

交叉極化

法蘭規格

方向圖包絡

Antenna Type

Operation Frequency(GHz)

Polarization

Gain(dBi)

3dB BW(°)

VSWR

F/B(dB)

XPD(dB)

Flange

ETSI RPE

Low

Mid

Top

WTG09-W71S

7.125-8.5

Single

34.0

34.8

35.5

3.0

1.3

60

30

153IEC-R84

Range1,Class3

WTG09-107S

10.7-11.7

Single

37.5

37.9

38.2

2.1

1.3

63

30

153IEC-R100

 Range1,Class3

WTG09-127S

12.75-13.25

Single

39.0

39.2

39.3

1.8

1.3

64

30

153IEC-R120

Range1,Class3

WTG09-144S

14.4-15.35

Single

40.1

40.3

40.6

1.6

1.3

67

30

153IEC-R140

Range2,Class3

WTG09-177S

17.7-19.7

Single

41.8

42.3

42.8

1.2

1.3

70

30

153IEC-R220

Range2,Class3

WTG09-212S

21.2-23.6

Single

43.4

43.9

44.3

1.0

1.3

67

30

153IEC-R220

Range3,Class3

WTG09-242S

24.25-26.5

Single

44.6

45.0

45.3

1.0

1.3

70

30

153IEC-R220

Range4,Class3

方位調節范圍 Coarse Azimuth, (degree)

360

方位微調范圍 Fine Azimuth Adjustment,(degree)

±15

俯仰調節范圍 Coarse Elevation,(degree)

±25

俯仰微調范圍 Fine Elevation Adjustment, (degree)

±15

抱桿直徑 Mounting Pie Diameter,(mm)

φ51~φ114

饋源氣密性 Feeder Watertightness

Watertight

工作風速 Wind velocity operational, (km/h)

110

生存風速 Wind velocity Survival Rating,(km/h)

250

工作溫度 Operational Temperature,(℃)

-45~+60

掛冰厚度 Ice-load,(mm)

25.4

加強桿 Strengthening rod

Have

包裝尺寸 Packing dimension,(mm)

1080×480×1320

凈重 Net weight,(kg)

36.5±1

毛重 Gross weight,(kg)

57±2

Antenna size.ft(mm)

A

B

C

D

Φ970

394

503

170

掛架表面處理 Surface Treatment of Mounting Kit

陽極氧化 GYB

抱桿直徑Pole Diameter

         φ51-φ114mm

凈重量Net Weight

            36.5kg

Axial Force(FA)

401(N)|90(lbf)

2184(N)|491(lbf)

Side Force(FS)

170(N)|38.2(lbf)

923(N)|207.4(lbf)

Twisting Moment(MT)

171(N·m)

932(N·m)
